DIMBREAK Break Dimension Lines. Here is a useful command that lets you easily add clarity to your dimensions. If you have ever dealt with dimension lines that cross over other dimension lines, you might recognize that these dimension lines can easily be confused for objects in the drawing. The old way of dealing with this was exploding. Create, Customize, Export and import AutoCAD Tool Palettes. View Larger Image; Tool palettes are a great tool that offers quick access to many AutoCAD tools and commands. You can expand the usability of AutoCAD tool palettes by making your own palette to store favorite blocks, dimension style, hatch patterns and even commands.
Here is a useful command that lets you easily add clarity to your dimensions. If you have ever dealt with dimension lines that cross over other dimension lines, you might recognize that these dimension lines can easily be confused for objects in the drawing.
The old way of dealing with this was exploding a dimension and then adding a break to one of the lines. This tool adds the break and yet keeps the dimension intact and associative.Plus, this tool will keep your drafting instructor at school happyHere’s how:. DIMBREAK at the command line or. Annotate tab on the ribbon Dimensions panel “Break” tool (as seen below). Select the dimension line that you want the break applied to.
Select the dimension line that crosses the first line. Where these dimension lines cross is where the break will occur.To change the size of the break that this command creates:Open the Dimension Style Manager. At the command line: D or DIMSTYLE. Or on the ribbon: click the diagonal arrow in the bottom of the “Dimension” panel of the Annotate tab of the ribbon.
Once in the Dim Styles manager:. Select the Dimension Style that you want to change and then click “Modify”.
Then click the “Symbols & Arrows” tab. Then at the bottom left of the dialog box, you can change the size of the break (as seen below).
Arguably the most valuable tool in the modern-day engineer’s toolbox is Microsoft Excel. People love Excel so much that after its launch in 1985 Microsoft redesigned the rest of the Microsoft Office programs to look more like it.
Microsoft Excel’s dominance is undoubtedly tied to its flexibility. After all, I think it’s fair to say that nearly all of us have at least one Excel table that is “wickedly complex”. The introduction of OLE objects, and more recently AutoCAD Tables were noble attempts to synchronize AutoCAD with Excel, but still fell short for many real-world needs.
What engineers wanted and needed was bidirectional synchronization between AutoCAD and Excel. Among the new features packed within AutoCAD 2008 is just that capability through use of Data Links.To set up Data Links:. Press the Ok button 3 times to get out of the command, and insert your linked table. Assuming you checked the “Retain Formulas” option when setting up the Data Link, you’ll notice fields (text with a grey background) for any calculated value.After inserting your Excel table, any updates made in the source Excel file will be updated in AutoCAD. By default however you will not be able to update data from AutoCAD, and have it update in the source Excel document.
To modify a table value in AutoCAD, select a cell, right-click, and navigate down to “Locking”, and select “Unlock”.After unlocking a cell, you can click into a cell, change a value. As a deliberate checks and balances, to update the Excel file, you must right-click once again, and select “Write Data Links to External Source“.So there you have it, a quick run-through on how to harness the new Data Links in AutoCAD 2008. Stay tuned for more in AutoCAD 2008.Update: If you found this post helpful, you might also be interested in my other post titled “ “. You can find it and all of my posts related to Microsoft Excel by clicking the Excel tag below. I am now using AutoCAD 2013.
